Teknisk specifikationer Contact resistance≤ 3 mΩ (inner) (inner) Contact resistance≤ 2 mΩ (outer) Dielectric strength1,5 kVdcInsulation resistance> 5 GΩ Rated voltage500 VVSWR≤ 1.050 / > 32 dB up to 1 GHz ≤ 1.065 / > 30 dB up to 2 GHz ≤ 1.100 / > 26 Cabel O.D.4.3 mm Cable retention> 30 N (Center) Crimp size1,6 Square crimp (pin) acc. IEC 60803 (die designation 2) Insertion force< 25 N Lifetime> 1000 mating cycles Cable anchoring Jacket crimping Contacts Brass (CuZn35Pb2), 0.2 µm AuCo (Center contact) Insert Teflon PTFE Shell Brass (CuZn39Pb3) Shell platingOptalloy® Standard complianceIEC 6016908, MIL 348A Temperature range-30 °C to +85 °C Contact crimpability Complies with IEC 60803 and IEC 60352-2
