Bullet tweeter - HT-958PA/SW - IMG STAGE LINE

Bullet tweeter - HT-958PA/SW - IMG STAGE LINE
  • På lager
  • På lager, 2-4 dage
  • Bedømmelse for Bullet tweeter - HT-958PA/SW - IMG STAGE LINE
    Produktet er endnu ikke bedømt
  •
    509,00DKK ved 1 stk.
Vis uden moms
Billigst på PriceRunner




Ring radiator tweeter, 30 W, 8 Ω
  • For PA and hi-fi
  • High efficiency
  • Very wide bandwidth radiation with an excellent linearity


Impedance (Z)8 Ω
Transmission method-
Frequency rangefx-20 kHz
Resonant frequency (fs)2.2 kHz
Rec. crossov. frequ. (fmax.) (12 dB/oct.)5 kHz
Power rating30 W
Peak music power output60 W
Sensitivity101 dB/W/m
Max. rated SPL-
Max. voltage-
Radiation angle, horizontal-
Radiation angle, vertical-
Suspension compl. (Cms)-
Moving mass (Mms)-
Mech. Q factor (Qms)-
Electr. Q factor (Qes)-
Total Q factor (Qts)-
Equivalent volume (Vas)-
DC resistance (Re)-
Force factor (BxL)-
Voice coil induct. (Le)-
Voice coil diameterØ 25.4 mm
Voice coil former-
Linear excursion (XMAX)-
Eff. cone area (Sd)-
Magnet weight-
Magnet diameterØ 72 mm
Mounting cutoutØ 75 mm
Mounting depth45 mm
Mounting hole diameter-
Hole spacing X-axis-
Hole spacing Y-axis-
DimensionsØ 97 mm x 45 mm
Outside diameterØ 97 mm
WidthØ 97 mm
Height-
Depth45 mm
Protective class-
Admiss. ambient temp.0-40 °C
Weight0.525 kg
Packing unit1
Type of speaker-

Varenr.: 102450
