If you're looking for a particularly natural-looking LED light for effects and lighting outdoors, then this IP65-rated Wash Beam Moving Head is the right choice. The warm white LED allows you to blend attractive warm pastel shades, and also delivers a wonderful warm white light for lighting people/objects/etc. The Cameo EVOS® W7 IP Wash Beam Moving Head with Single Pixel Control is devices, the Cameo EVOS® W7 IP offers a particularly high colour reproduction index. The warm white chip can be used to light people or objects - either with naturally warm white light or as mood lighting in pastel shades. This versatility results from the unique combination of a full-colour LED with a WW chip, which generates extremely clearly defined white tones with a CRI above Ra 90.
Providing individual control of all LEDs by means of Single Pixel Control, the Cameo EVOS® W7 IP Wash Beam Moving Head produces breath-taking pixel effects. The powerful luminous flux floods any event with warm, bright light in clearly defined colours and delivers generous coverage up to 540° horizontally (pan) and 270° vertically (tilt). Its versatility is further enhanced by an impressive zoom range of 4.5° to 55°, which facilitates powerful beam and large-area wash effects.
Live broadcast images of your event are guaranteed to be flicker-free because the Wash Beam Moving Head's refresh rate can be adjusted in six stages between 800 Hz and a maximum of 25 kHz.
Software control via a network is highly flexible with DMX, RDM Art-Net3, sACN or KlingNet. Further effect devices in the network are looped through via 5-pin XLR sockets. Independent operation and mains-independent configuration in Auto Program and Static Mode are carried out via the 4 touch buttons with battery-powered graphic display. Preset colour filters allow problem-free use in combination with conventional headlamps.
LED Moving Lights
Type
Moving Head
Colour spectrum
RGBWW
Number of LEDs
19
LED type
40 W RGBWW
Refresh rate
800 Hz, 1200 Hz, 2000 Hz, 3600 Hz, 12 kHz, 25 kHz - adjustable Hz
Dispersion
Beam Angle: 4.5 ° - 34 °, Field Angle: 7 ° - 55 °
DMX input
Network, XLR 5-pin male IP65
DMX output
Network, XLR 5-pin female IP65
DMX mode
16-channel, 18-channel, 23-channel, 33-channel, 43-channel, 87-channel
DMX Functions
Colour presets, Device Settings, Dimmer, Dimmer Fine, Effect patterns, Motion Macro, Pan/Tilt, Pan/Tilt fine, Patterns, Single Pixel Control, Strobe, Zoom, Zoom Fine
Control
ArtNet 3, DMX, KlingNet, sACN, W-DMX
PAN movement
540 °
TILT movement
270 °
Standalone modes
Art-Net3, DMX512, KlingNet, RDM enabled, sACN
Controls
Encoder wheel
Indicators
Backlit colour LCD display, Battery supply for mains-independent system settings (automatically rechargeable battery)
Operating voltage
100 V AC - 240 V AC, 50 - 60 Hz
Power consumption
900 W
Fuse
T10AL 250 V
Power supply connector
Neutrik TrueOne Input
Housing material
Environment-friendly fire-retardant ABS, nylon and polycarbonat
Cabinet colour
Black
Protection class IP
IP65
Luminous flux
12500 lm
Width
400 mm
Height
569 mm
Depth
330 mm
Weight
25 kg
