Teknisk specifikationer Contact resistance< 10 mΩ (inner) (XLR) Contact resistance< 20 mΩ (outer) Dielectric strength1,5 kVdc Insulation resistance> 2 GΩ (initial) Rated current per contact7,5 A (XLR) Rated current per contact7,5 A (Jack )Rated voltage50 V Switching contacts 3 Insertion force≤ 25 N With drawal force≤ 25 N Lifetime> 1000 mating cycles Panel thicknessmax. 7 mm 0.27 Mounting direction rear Contact plating0.2 µm Au hard alloy over 2 µm Ni Contacts Bronze (CuSn6) Insert Polyamide (PA 6.6 30 % GR) Locking element Steel Ck67 Temperature range-30 °C to +80 °C
