FEATURES
High Efficiency 380W White LED Engine, 91CRI
Dual Color Wheel (Solids and Color Corrections)
Rotating Gobo Wheel
Full Blackout Framing System
Iris and Frost
Wide Zoom Range from 9° to 43°
SOURCE
380W 6,000K White LED Engine
30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
PHOTOMETRIC DATA
11,200 Total Lumen Output
CRI 91
Zoom Range 9° - 43°
Beam Angle 9.3° - 43.1°
Field Angle 10.3° - 46.8°
EFFECTS
Motorized Zoom
4 Rotating Full Blackout Framing Blades, +/- 60° Index
Variable Frost Filter
Motorized Iris
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
Adjustable LED Refresh Rate Frequency
Pan Angle: 540°/630°
Tilt Angle: 270°
COLOR
2 Color Wheels
7 Solid Colors
7 Color Corrections and UV
GOBOS
1 Gobo Wheel
7 Rotating / Indexing Interchangeable Glass Gobos
CONTROL / CONNECTIONS
2 DMX Channel Modes (26 / 40)
16-bit Pan, Tilt, and Dimming Control
Motorized Focus
DMX, RDM Protocol Support
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
16 Bit Resolution Adjustable Movement
Hibernation Mode (Power Save)
5pin DMX In/Out
IP65 Locking Power Cable In/Out
With Wired Digital Communication Network
SIZE / WEIGHT
Length: 408mm (15.9”)
Width: 252mm (9.9”)
Vertical Height: 698mm (27.4”)
Weight: 23.3kg (51.4 lbs.)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
590W Max Power Consumption
-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 2011.9
