Elation Rayzor 760, 7x 60W RGBW LED Zoom 5° - 77°

Fjernlager
Kontakt os om leveringstid
Bedømmelse for Elation Rayzor 760, 7x 60W RGBW LED Zoom 5° - 77°
Produktet er endnu ikke bedømt

41.120,00DKK ved 1 stk.

Vis uden moms

FEATURES

LED Wash Effects Fixture

7x 60W OSRAM RGBW LED with Pixel Control

28x 2W SparkLED™ Effect with Pixel Control (patent pending)

Extreme Zoom – 5° for Mid-Air Beam to 77° for Even Washes

Fast and Precise 360° Continuous Pan and Tilt Rotation

Beam FX and Smooth Wash Fixture in a Compact Housing

SOURCE

(7) 60W Osram RGBW LEDs

(28) 2W White SparkLED™

50,000 Hour Average LED Life*

*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

PHOTOMETRIC DATA

8,400 Total Lumen Output
CRI 80

Zoom Range 5° - 77°
Beam Angle 5.4° - 57.3°
Field Angle 7.4° - 73.3°

EFFECTS

Motorized Zoom

Linear Color Temperature Presets (2,700 - 8,000K)

RGBW Color Mixing and Pixel Control

White SparkLED Lens Effect

Color Presets and Macros

Electronic Strobe and Variable Dimming Curves

16-bit Dimming

Pan Angle: 540°/630°
Tilt Angle: 270°/360°

CONTROL / CONNECTIONS

3 DMX Channel Modes (25 / 52 / 80)

360° Continuous Pan and Tilt Movement

900 - 25,000 Hz DMX Adjustable Refresh Rate

6 Button Touch Panel

Full Color 180° Reversible LCD Menu Display

DMX, RDM, Art-NET, and sACN Protocol Support

5pin XLR DMX In/Out

RJ45 Ethernet In/Out

Locking Power Cable In/Out

USB Connection (Firmware Updates)

With Wired Digital Communication Network

SIZE / WEIGHT

Length: 340.4mm (13.4”)

Width: 218.0mm (8.58”)

Vertical Height: 423.4mm (16.67”)

Weight: 12.2 kg (27 lbs.)

ELECTRICAL / THERMAL

AC 100-240V 50/60Hz

700W Max Power Consumption

-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 2216.5

Dataark / Info Blad

Varenr.: M-1237000191
