Power supply: | 100-240 V AC, 50/60 Hz, |
| via supplied power unit |
Video: |
8 x inputs: | 1 Vpp/ 75 ohms, composite RCA |
2 x outputs: | 1 Vpp/ 75 ohms, composite RCA |
Gain: | 2 V, 1 V (terminated)/ 75 ohms |
Return loss: | >18 dB |
Video bandwidth: | >100 MHz |
Audio: |
8 x inputs: | 22 kohms, stereo RCA |
2 x output: | 1 kohms, stereo RCA |
Gain: | nominal 0 dB |
THD: | 0.05 % |
Channel separation: | >75 dB |
S/N ratio: | 100 dB |
Dimensions: | 282 x 128 x 50 mm |
Weight: | 1 kg |
Power consumption: | 6.00 W |
Frequency range: | 20 - 100 Hz |
Height: | 5 cm |
Depths: | 12,8 cm |
Width: | 28,2 cm |
