NYS228C-4
0-Sort, 2-Rød, 4-Gul, 5-Grøn, 6-Blå
NYS228C-4 Jackstik REAN, metalhus, stereo, gul markering
3 polet 1/4" stik, metalhus, gul markering.
0-Sort, 2-Rød, 4-Gul, 5-Grøn, 6-Blå
Dielectric strength: 0.5 kVdc
Insulation resistance: ≥ 1 GΩ
Contact resistance: depends on mating connector
Rated current: depends on mating connector
Cable O.D.: ≤ 6 mm
Lifetime: 1000 mating cycles
Wiresize: 24 AWG
Contact plating: 2 µm Ni
Contacts: Brass (CuZn39Pb3)
Shell: Zinc diecast (ZnAl4Cu1)
Shell plating: Nickel
Insulation: Thermoplastic
Strain relief: Crimp type SnCe plated
Solderability: Complies with IEC 68-2-20
Temperature range: - 20 °C to +70 °C
