| Active/passive | passive |
| Transmission method | - |
| Impedance | 16 Ω |
| Frequency range | 160-6,500 Hz |
| Power rating | - |
| Max. power | - |
| THD | - |
| S/N ratio | - |
| Input signal | - |
| System | - |
| Full range speaker | - |
| Bass speaker | - |
| Midrange speaker | - |
| Tweeter | - |
| Number of speakers | 1 |
| Speaker size | - |
| Power rating | 50 W |
| Peak music power output | 75 W |
| Sensitivity | 113 dB/W/m |
| Max. rated SPL | - |
| Radiation angle, horizontal | dep. on horn |
| Radiation angle, vertical | dep. on horn |
| Features | - |
| Housing material | diecast |
| Colour | dark grey |
| Mounting facility | 3.5 mm mounting flange |
| Protected against ball rebound | - |
| Protective class | IP66 |
| Admiss. ambient temp. | -20 to +50 °C |
| Power supply | - |
| Width | Ø 125 mm |
| Height | - |
| Depth | 100 mm |
| Weight | 1.9 kg |
| Inputs | - |
| Outputs | - |
| Replacement voice coil | KU-516/VC |
| Other features | weatherproof |
| Accessories | |
