| Active/passive | passive |
| Transmission method | 100 V |
| Impedance | - |
| Frequency range | 160-6,500 Hz |
| Power rating | - |
| Max. power | - |
| THD | - |
| S/N ratio | - |
| Input signal | - |
| System | - |
| Full range speaker | - |
| Bass speaker | - |
| Midrange speaker | - |
| Tweeter | - |
| Number of speakers | 1 |
| Speaker size | - |
| Power rating | 40/30/20/10/5 W |
| Peak music power output | - |
| Sensitivity | 112 dB/W/m |
| Max. rated SPL | - |
| Radiation angle, horizontal | - |
| Radiation angle, vertical | - |
| Features | power selector switch |
| Housing material | metal |
| Colour | black |
| Mounting facility | 3.5 cm mounting flange |
| Protected against ball rebound | - |
| Protective class | IP66 |
| Admiss. ambient temp. | -20 to +50 °C |
| Power supply | - |
| Width | Ø 150 mm |
| Height | - |
| Depth | 136 mm |
| Weight | 2.2 kg |
| Inputs | - |
| Outputs | - |
| Replacement voice coil | KU-616T/VC |
| Other features | weatherproof |
| Accessories | |
