No. of channels | 8 |
No. of inputs | 8 |
Mic input | 1 mV/6.6 kΩ (mic), 6 x XLR, bal. |
Line input | 250 mV/30 kΩ, 2 x XLR , bal. 100 mV/40 kΩ, 6 x XLR, bal. |
CD input | - |
Phono input | - |
Tape (play) | - |
Aux input | - |
Insert input | - |
Effect return | - |
Master output | 1 V/200 Ω, 6 x XLR, bal. (mono), 1 x XLR L/R, bal. (stereo) |
Record output | - |
Monitor output | - |
Booth output | - |
Aux output | - |
Insert output | - |
Effect send | - |
Control room | - |
Tape (rec) | - |
Headphones | - |
Gooseneck lamp | - |
WiFi | - |
USB | - |
Frequency range | 10-30,000 Hz |
THD | 0.02% |
S/N ratio | 81 dB, weighted |
Crosstalk | -63 dB |
Equalizer bass | - |
Equalizer midrange | - |
Equalizer treble | - |
equalizer | - |
Talkover | - |
Phantom power | - |
Crossfader | - |
Media player | - |
Amplifier | - |
Power supply | ∼ 230 V/50 Hz/10 VA |
Mains voltage | ∼ 230 V |
Mains frequency | 50 Hz |
Power consumption, operation | 10 VA |
Operating voltage (possible alternative) | - |
Power supply (possible alternative) | - |
Admiss. ambient temp. | 0-40 °C |
Width | 482 mm |
Height | 48 mm |
Depth | 200 mm |
Rack spaces, RS | 1 |
Weight | 2.9 kg |
