Type | microphone preamplifier |
Frequency range | 20-20,000 Hz |
Control range | - |
Control frequencies | - |
Input signal | - |
Input sensitivity | 0.16-150 mV schaltbar |
Input impedance | 4.4 kΩ (bal.)
2.2 kΩ (unbal.) |
Output signal | 1-14 V (line, bal.) 1-7 V (line, stereo) |
Output impedance | 100 Ω/600 Ω |
Gain | 15-75 dB |
Phantom power | - |
Compression | - |
Gate ratio | - |
Crossover frequency | 15-240 Hz, 6 dB/oct. (low cut), 15 Hz, 18 dB/oct. (subsonic) |
High-pass filter | - |
Low cut | 15-240 Hz, 6 dB/oct. |
Transmission ratio | - |
S/N ratio | > 68 dB, unweighted > 87 dB, weighted |
Channel separation | - |
THD | < 0,01% |
Admiss. ambient temp. | 0-40 °C |
Power supply | via encl. plug-in power supply |
Dimensions | 116 x 55 x 135 mm |
Weight | 980 g |
Inputs | 2 x XLR |
Outputs | 2 x XLR
2 x RCA |
Other features | - |
