| Type: | Wireless set |
| Frequency band: | UHF 823 - 832 MHz; UHF 863 - 865 MHz |
| Frequency range: | 50 - 18,000 Hz |
| Number of channels: | 2 |
| Range: | 60 m |
| Weight: | 2,30 kg |
| Receiver |
| Power supply: | 110-240 V AC, 50/60 Hz
14 V DC 350 mA |
| Power consumption: | 4 W |
| Power connection: | Mains input Coaxial power connector (M) Power supply cord with AC adapter (provided) |
| Material: | Metal |
| Housing design: | (19") 48.3 cm rack installation possible 1 U |
| Width: | 41 cm |
| Height: | 4,7 cm |
| Depth: | 23,5 cm |
| Microphone |
| Power supply: | 3 V DC |
| Polar pattern: | Cardioid |
| Battery: | 2 x Mignon (AA) (not included) |
| Power connection: | Battery/battery pack |
| Capsule type: | Dynamic |
| Material: | Plastic |
| Length: | 25 cm |
| Diameter: | 5,1 cm |
| Weight: | 0,23 kg |
| System: | Non-diversity, 2 channels |
| Receiving frequencies: | 93 |
| RF power output: | 10 mW |
| Modulation method: | FM |
| Frequency stability: | 10 ppm |
| Sensitivity: | 6 dBµV |
| S/N ratio: | >80 dB |
| T.H.D.: | <0.5 % at 1 kHz |
| Audio outputs: | |
| Mic: | 2 x XLR, bal. |
| Mix: | 6.3 mm jack, unbal. |
| Current consumption: | 130 mA |
