Teknisk specifiaktioner Capacitance
between contacts≤ 9 pF Contact resistance<5G mΩ (inner) Dielectric
strength0,5 kVdc Insulation resistance< 5 GΩ Rated current per
contact16 A Rated voltage50 V Lifetime> 2000 mating cycles Wiring
Solder contacts Mounting direction front Chassis shape D Contact plating5
µm Au over 5 µm Ni Contacts Brass (CuZn39Pb3) Shell Zinc diecast
(ZnAl4Cu1) Flammability UL 94 HB Standard compliance IEC
601-14 Protection class IP 40 Solderability Complies with IEC
68-2-20 Temperature range-30 °C to +80 °C
