RCF IPS 2.5K 2 kanals professionel power forstærker
IPS-serien er en serie af to-kanals professionelle forstærkere, der kombinerer den nyeste højtydende klasse H effektforstærkningsteknologi med langsigtet pålidelighed.
IPS 2.5K er en 2-kanals effektforstærker, der leverer op til 2 x 1250 Watt ved 4 Ohms impedans.
Den har uafhængig forstærkningskontrol, signal/klip og fejlindikatorer, stereo XLR input og output link, stereo/parallel/bridge switch, speakON og binding post output stik.
Desuden er den beskyttet mod kortslutninger.
Takket være dets højeffektive køleplader og ventilatorer med variabel hastighed kan IPS 2.5K modstå ekstreme varmeforhold, hvilket sikrer fuldstændig pålidelighed.
2 x 1250 W Class-H Power
Fast response and low distortion
Stereo, parallel, bridge modes
Extensive protection circuit
Variable speed cooling system
Signal, clip, fault led indicators
XLR input connectors
speakON and binding post output connectors
Limiter on each channel
1 CH B OUTPUT
Channel B output to loudspeakers (SPEAKON and BINDING POST connectors). Do not use this output if the amplifier is set to BRIDGE mode. See both ‘Operation modes’ and ‘SPEAKON connector wiring’ manual sections.
2 CH A OUTPUT
Channel A output to loudspeakers (SPEAKON and BINDING POST connectors). If the amplifier is set to BRIDGE mode, only connect this output. See both ‘Operation modes’ and ‘SPEAKON connector wiring’ manual sections.
3 CH A INPUT
Channel A balanced audio input (female XLR connector).
4 CH A LINK
Channel A balanced parallel audio output (male XLR connector). This output is linked in parallel with the channel A input and is useful to link another amplifier.
5 SENSITIVITY switch
Set the sensitivity switch to either 0.775 V or 1.4 V, which is input signal voltage required to get the maximum power output from the amplifier.
6 CH B INPUT (STEREO MODE ONLY)
Channel B balanced audio input (female XLR connector).
7 CH B LINK
Channel B balanced parallel audio output (male XLR connector). This output is linked in parallel with the channel B input and is useful to link another amplifier.
8 MODE switch
Before turning the amplifier on, set the amplifier mode selector to the right position among BRIDGE, PARALLEL (mono) and STEREO. See the ‘Operation modes’ manual section.
9 RESET button
Push this button to reset the amplifier when is muted due to the thermal protection.
IPS are high-performance, versatile 2U power amplifiers for install applications, using sophisticated Class-H topology for two single-channel outputs, two parallel outputs, or a single-channel bridge operativity. High quality, low distortion audio output, flawless reliability and safety, industry-standard speakON connectors, and binding post terminals make IPS Series electronics the workhorse solution for mobile sound systems and permanent installation applications
.The Advantage of Class H
Class-H amplifiers modulate the supply voltage to the amplifier output devices so that it is never higher than necessary to support the signal swing. This reduces dissipation across the output devices connected to that supply and allows the amplifier to operate with an optimized efficiency, regardless of output power level. Up to full power, a Class-H design will require less energy than a pure class AB design, and is better suited for high-power applications.
Remarkable Audio Performance
With a very high signal-to-noise ratio, IPS amplifiers also boast a very low total harmonic distortion, making it perfect for highly demanding music applications hence delivering perfect vocal intelligibility.
Self-protecting Architecture
IPS Amplifiers implement several safety strategies protecting both the amplifier and the sound system, including an effective peak limiting protection for the transducers. The temperature-controlled continuous variable speed double-fan system (front to back), combined with the high-efficiency heat sinks, allows the amplifier to maintain the optimal working temperature, no matter the environmental temperature or the power output. The circuit is protected from overheating and short circuits, also including protections against infrasonic DC and Very High Frequency (VHF) peaks from non-musical signals that could damage transducers.
AMPLIFIER SPECIFICATIONS
Amplifier Class: H
Output power:
2 x 1250 W @ 4 ohm
2 x 800 W @ 8 ohm
1 x 2500 W @ 8 ohm (bridge)
Frequency Response (-3dB): 20 Hz ÷ 22000 Hz
Crosstalk: Distortion (THD+N) @ 1 kHz nominal power:
INPUT SECTION
Total number of inputs: 2
Balanced: 2
Mono: 2
Line inputs: 2
Line connectors: XLR
OUTPUT SECTION
Signal output number: 2
Signal output connectors: XLR
Power output connectors: Binding Post, Speakon
CONFIGURATION AND CONTROL
Configuration: DIP switch, Front panel
PROTECTIONS
Cooling: Forced
Short circuit: Yes
Thermal: Yes
DC: Yes
Fuses: Yes
VHF (Very High Frequencies): Yes
POWER REQUIREMENT
Operating voltage: 220-240/115 V~ 50/60Hz
Power consumption (MAX): 900 W
STANDARD COMPLIANCE
Safety agency: CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material: Metal
Color: Black - RAL 9005
Rack mounting: 19", 2U
SIZE
Height: 88 mm / 3.46 inches
Width: 482 mm / 18.98 inches
Depth: 325 mm / 12.69 inches
Weight: 11.2 kg / 24.69 lbs
SHIPPING INFORMATION
Package Height: 140 mm / 5.51 inches
Package Width: 550 mm / 21.65 inches
Package Depth: 530 mm / 20.87 inches
Package Weight: 12,7 kg / 28.0 lbs
