NYS228C-6 0-Sort, 2-Rød, 4-Gul, 5-Grøn, 6-Blå
NYS228C-6 Jackstik REAN, metalhus, stereo, blå
markering
3 polet 1/4" stik, metalhus, blå markering.
0-Sort,
2-Rød, 4-Gul, 5-Grøn, 6-Blå
Dielectric strength: 0.5 kVdc
Insulation
resistance: = 1 GO
Contact resistance: depends on mating connector
Rated
current: depends on mating connector
Cable O.D.: = 6 mm
Lifetime: 1000
mating cycles
Wiresize: 24 AWG
Contact plating: 2 µm Ni
Contacts: Brass
(CuZn39Pb3)
Shell: Zinc diecast (ZnAl4Cu1)
Shell plating:
Nickel
Insulation: Thermoplastic
Strain relief: Crimp type SnCe
plated
Solderability: Complies with IEC 68-2-20
Temperature range: - 20 °C
to +70 °C
