Teknisk specifikationer Contact resistance< 10 mΩ (inner) Dielectric strength1 kVdc Frequencyrange1 - 250 M HzInsulation resistance> 0.5 GΩ Rated current per contact1,5 A Rated voltage50 V Transmission performance CAT 6 Standard compliance TIA/EIA 586B, IEC11801 Insertion force≤ 40 N Withdrawal force≤ 20 N Lifetime> 1000 mating cycles Panel thicknessmax. 3 mm 0.12'' Wire size0.5 - 0.65 mm² Wire size24 - 22 AWG Wiring IDC punch down terminals Locking device Push-Pull Mounting direction front & rear Chassis shape D Contact plating 0.7 µm Au over 1.2 µm Ni plating Contacts Bronze (CuSn8) Insert Polycarbonate Shell Zinc diecast (ZnAl4Cu1) Shell plating Nickel Strain relief Stainless steel FlammabilityUL 94 HB Protection class IP 65 Temperature range-10 °C to +60 °C
