4 pole chassis connector, black D-size flange, self tapping screw holes (A-screw), switchable version of NL4MD-V with 8 vertical PCB contacts (4 switching contacts). Switch is closed unless mating of speakON cable connector. This chassis connector is not
Teknisk specifikationer Contact resistance≤ 3 mΩ Dielectric strength4 kVdc Insulation resistance> 1 GΩ Rated current per contact20 A rms continuous Rated current per contact40 A audiosignal, duty cycle 50 % Rated voltage250 V (AttentionspeakON is NOT to be used as an AC mains or power supply connector) Lifetime> 5000 mating cycles Locking device Quick LockChassis shape D Layout standard hole position, self tapping screw holes Contact plating 4 µm Ag Contacts Bronze (CuSn6) Shell Polyamide (PA 6 30 % GR) red Flammability UL 94 HB Solderability Complies with IEC 68-2-20 Temperature range-30 °C to +80 °C
