4 pole male cable connector, black-chrome metal housing, chuck type strain relief. The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series feat
Teknisk specifikationer Contact
resistance< 2 mΩ Dielectric strength4 kVdc Insulation resistance> 10
GΩ Rated current per contact40 A rms continuous Rated current per
contact50 A audiosignal, duty cycle 50 % Rated voltage250 V (AttentionspeakON
is NOT to be used as an AC mains or power supply connector) Cabel O.D.9 - 16
mm Cable retention≥ 220 N Lifetime> 5000 mating cycles Wire size 6
mm² Wire size10 AWG Locking device Quick Lock Contact plating 4 µm
Ag Contacts Spring Copper (CuSn0.2) Insert Polyamide (PA 6 30 %
GR) Locking element Zinc diecast (ZnAl4Cu1) Shell Zinc diecast
(ZnAl4Cu1) Strain relief Polyacetal Flammability UL 94 HB Protection
class IP 54 SolderabilityComplies with IEC 68-2-20 Temperature range-30 °C
to +80 °C
