No. of channels | 2 |
No. of inputs | 3 |
Mic input | 0.5 mV, 1 x 3-pole XLR |
Line input | 150 mV (stereo), 1 x RCA L/R 2 mV (mono), 6.3 mm jack |
CD input | - |
Phono input | - |
Tape (play) | 420 mV, 1 x RCA L/R |
Aux input | - |
Insert input | - |
Effect return | - |
Master output | 6 V max., 1 x 3.5 mm jack |
Record output | - |
Monitor output | - |
Booth output | 6 V max., 1 x 3.5 mm jack |
Aux output | - |
Insert output | - |
Effect send | - |
Control room | - |
Tape (rec) | 1 x RCA L/R |
Headphones | - |
Gooseneck lamp | - |
WiFi | - |
USB | yes |
Frequency range | 20-20,000 Hz |
THD | < 0.05% |
S/N ratio | 81 dB, weighted |
Crosstalk | - |
Equalizer bass | ±15 dB/80 Hz |
Equalizer midrange | - |
Equalizer treble | ±15 dB/12 kHz |
equalizer | - |
Talkover | - |
Phantom power | +20 V |
Crossfader | - |
Media player | - |
Amplifier | - |
Power supply | via USB interface or via encl. power supply |
Mains voltage | - |
Mains frequency | - |
Power consumption, operation | - |
Operating voltage (possible alternative) | DC current 5 V |
Power supply (possible alternative) | DC current 500 mA |
Admiss. ambient temp. | 0-40 °C |
Width | 102 mm |
Height | 45 mm |
Depth | 140 mm |
Rack spaces, RS | - |
Weight | 430 g |
