Teknisk specifikationer Capacitance
between contacts≤ 4 p FContact resistance≤ 3 mΩ (inner) Dielectric
strength1,5 kVdc Insulation resistance> 2 GΩ (initial) Rated current
per contact16 A Rated voltage50 V Cabel O.D.3.5 - 8.0 mm Insertion
force≤ 20 N Withdrawal force≤ 20 N Lifetime> 1000 mating cycles
Wiresizemax. 2.5 mm²Wiresizemax. 14 AWG Wiring Solder contacts Locking
device Latch lock Boot Polyuretan Bushing Polyamide (PA 6 15%
GR) Contact plating0.2 µm Au Contacts Brass (CuZn39Pb3) male Insert
Polyamide (PA 6.6 30 % GR) Locking element Zinc diecast (ZnAl4Cu1) / Ck 67
(spring) Shell Zinc diecast (ZnAl4Cu1) Shell plating Nickel Strain
relief Polyacetal (POM) FlammabilityUL 94 HB Standard compliance IEC
61076-2-103 Protection classIP 40 SolderabilityComplies with IEC
68-2-20 Temperature range-30 °C to +80 °C
