| Power supply: | 230 V AC, 50 Hz |
| Protection class: | Protection class II |
| Power connection: | Power supply cord with Euro plug (provided) |
| Frequency range: | 20 - 20000 Hz |
| S/N ratio: | >65 dB line/phono |
| THD: | Line/phono <0,02 % at 1 kHz |
| Gain: | Microphone 52 dB
Line 19 dB
Phono 54 dB |
| Housing color: | Black |
| Control elements: | Power switch, regular talkover, source selector |
| Status LED: | Signal, master level meter, peak, chanal source; CUE, Talkover, ON AIR, Routing |
| Connections: | Input: Microphone via 2 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version)
Input: line/phono via 2 x stereo RCA
Input: line via 9 x stereo RCA
Output: master via 2 x 3-pin XLR
Output: master via 2 x stereo RCA
Output: headphones via 1 x 6.3-mm-jack (bal.)
Output: booth via stereo RCA
Output: rec. via 2 x stereo RCA |
| Channels: | Input chanel: 2 x stereo with Line-Line/Phono switch via RCA, channel control via fader, gain control, source selector, CUE switch
Input chanel: 3 x stereo with Line-line switch via RCA, channel control via fader, gain control, source selector, CUE switch
Microphon chanal: 2 x mono via Combination socket (XLR/jack), channel control via Rotary dial, 3-band tone control EQ, ON AIR switch, Talkover switch,
Master output: 2 x stereo via XLR or RCA, channel control via Rotary dial, 3-band tone control EQ
Rec. output: 2 x stereo via RCA, NO MIC switch,
Headphones output: 1 x stereo via Jack, channel control via Rotary dial, Cue mix split function,
Booth output: 1 x mono + stereo via RCA, channel control via Rotary dial
Input chanel: 1 x stereo via RCA, channel control via Rotary dial |
| Housing design: | (19") 48.3 cm rack installation 2 U |
| Dimensions: | Width: 48,3 cm
Depth: 14,8 cm
Height: 8,9 cm |
| Weight: | 3,00 kg |
